004.1 – Washer disk ⌀ 40mm

Basic info

• Washer
• material: strong
• measures: outer diameter ~40mm, thickness ~16mm
• holes: one center hole ⌀ 10mm (but it can also be slightly bigger)

Tolerance

• Size: standard tolerance
• Material: standard tolerance

Get this part

• Buy: Available as local make. But you can get washers for M10 in stores. The holes in these off the shelf M10 washers are a bit bigger than 10mm. But they might work for your use case equally well.
• Make: One way to make this is to use a laser cutter. → Download vector file here.

Introduced by

• Lars Zimmermann via Platform Clocks
• Open: Shared under TPP 1.0
• Original post (18), original post backup pdf (18)
